Nickel alloy bar


Nickel alloy is an alloy based on nickel and added with other elements. The Monel alloy containing about 30% copper, produced around 1905, is an earlier nickel alloy.

Nickel has good mechanical, physical and chemical properties. Adding appropriate elements can improve its oxidation resistance, corrosion resistance, high temperature strength and improve certain physical properties.

Nickel alloys can be used as materials for electron tubes, precision alloys (magnetic alloys, precision resistance alloys, electrothermal alloys, etc.), nickel-based high-temperature alloys, nickel-based corrosion-resistant alloys, and shape memory alloys.

Nickel alloys are widely used in sectors such as energy development, chemicals, electronics, navigation, aviation and aerospace.

Description

Nickel alloy is an alloy based on nickel and added with other elements. The Monel alloy containing about 30% copper, produced around 1905, is an earlier nickel alloy. Nickel has good mechanical, physical and chemical properties. Adding appropriate elements can improve its oxidation resistance, corrosion resistance, high temperature strength and improve certain physical properties. Nickel alloys can be used as materials for electron tubes, precision alloys (magnetic alloys, precision resistance alloys, electrothermal alloys, etc.), nickel-based high-temperature alloys, nickel-based corrosion-resistant alloys, and shape memory alloys. Nickel alloys are widely used in sectors such as energy development, chemicals, electronics, navigation, aviation and aerospace.

Alloy steel has higher strength and toughness than carbon steel, and its reinforcement effect with the increace of tissue imbalance and tend to be more obvious, and the strength of the alloy steel annealing state than carbon steel has a lot of advantages, and in normalizing, than obviously increase the carbon steel and the strength of the alloy steel after quenching and tempering, the steel reinforcement effect is the most significant. Some alloy steels have excellent thermal hardness and other special properties, such as heat resistance, corrosion resistance, wear resistance and magnetic properties.


Product Parameter

Product name Nicel Alloy pipe tube
Grade

Nckel :Ndke200/201/205Hastelloy:HastelloyB/-2/B-3/C22/C-4/S/ C276

/C-2000/G-35/G-30/X/N/g Hastellcy B/UNS NI0001,Hastellcy B-2/

UNS N10665/DIN W.NC2.4612R602,Hasteloy-4955Haynes:Haynes 230/

556/188Inconel:Inconel 600/601/602CA/617/625/713/718/738/x-750,

Carpenter 20 Inconel 718/UNS NO7718/ DEN W. Nr.2.4668,Inconel 601/

UNSH 725/UNS NO7725,Inconel x-750/UNS NO7750/DIN W.Incoloy:

Incoloy 800/800H/800HT/825/925/9261Monel:Monel 400/k500/R405jetc.

Standard GB.AISLASTH,DINEN,SUS,UNS ett
Diameter Peeling Bar:16~150mmCold Draan Bar:4.76 omm be customied)
Length 3m-12m,or as required.
Surface Mil.polshed.bright.olled.hair line.brushumirrocsand blast./oras
Certis-des CE,ISO,SGS,ETC
MOQ 6 1ons
delivery time Usualy 7 days, depending on the quantity
Padkage Export standard package: bundied wooden box,suit for all lands of transport,or be requred
Application

High temperature componerts such as turbine blades,guie vanes,turbine diks

, high pressuredhfct

compressorsks,macine manuauringand combuation chambers used in the

manufacture of avation,naval and industnal gas turbines.enc

DIN/EN UNS No Generic term Material
1 2.4060 NO2000 Nickl200 99Ni-0.15Fe-0.2Mn-0.1Si-0.1Cu-0.1C
2 2.4601 NO2201 Nickl201 99Ni-0.15Fe-0.2Mn-0.1Si-0.1Cu-0.01C
3 2.4050 NO2270 Nickl270 99.9Ni-0.02Fe-0.001Mn-0.002Si-0.005Cu-0.01C
4 1.4980 S66286 INCOLOY Alloy A286 25Ni-15Cr-1.5Mo-2Ti-1Mg-0.03C
5 N08367 INCOLOY Alloy 25-6HN 25Ni-20Cr-6.3MO-0.25Cu-0.2N-0.01P-0.05S-0.01C
6 1.4529 N08926 INCOLOY Alloy 25-6Mo 25Ni-20Cr-6.5Mo-1Cu-0.2N-1.0Mg-0.01P-0.005S-0.01C
7 2.4460 N08020 INCOLOY Alloy 20 36Ni-21Cr-3.5Cu2.5Mo-1Mn-0.01C
8 1.4563 N08028 INCOLOY Alloy 28 32Ni-27Cr-3.5Mo-1Cu-0.01C
9 1.4886 N08330 INCOLOY Alloy 330 35Ni-18Cr-2Mg-1SI-0.03C
10 1.4876 N08800 INCOLOY Alloy 800 32Ni-21Cr-0.3~1.2(Al+Ti)0.02C
11 1.4876 N08810 INCOLOY Alloy 800H 32Ni-21Cr-0.3~1.2(Al+Ti)0.08C
12 2.4858 N08825 INCOLOY Alloy 825 42Ni-21Cr-3Mo-2Cu-0.8Ti-0.1AI-0.02C
13 2.4816 N06600 Inconel 600INCOLOY Alloy 600 72Ni-151Cr-8Fr-0.2Cu-0.02C
14 2.4851 N06601 Inconel 601INCOLOY Alloy 601 60Ni-22Cr-1.2Al-0.02C
15 2.4856 N06625 Inconel 625INCOLOY Alloy 625 58Ni-21Cr-9Mo-3.5Nb-1CO-0.02C
16 2.4856 N06626 Inconel 600LCFINCOLOY Alloy625LCF 58Ni-21Cr-9Mo-3.5Nb-1CO-0.02C
17 2.4606 N06686 Inconel 686INCOLOY Alloy 686 57Ni-21Cr-16Mo-4W-0.01C

18 2.4642 N06690 Inconel 690INCOLOY Alloy 690 58Ni-30Cr-9Fe-0.2Cu-0.02C
19 2.4668 N07718 Inconel 718INCOLOY Alloy 718 52Ni-19Cr-5Nb-3Mo-1Ti-0.6Al-0.02C
20 2.4669 N07750 Inconel X750INCOLOY Alloy 750 70Ni-15Cr-6Fe-2.5Ti-0.06Al-1Nb-0.02C
21 2.4360 N04400 MONEL400 63Ni-32Cu-1Fe-0.1C
22 2.4375 N05500 MONEL K-500 63Ni-30Cr-1Fe-3AI-0.6Ti-0.1C
23 2.4819 N10276 Hastelloy C-276 57Ni-16Mo-16Cr-5Fe-4W-2.5Co-1Mn-0.35V-0.08Si-0.01C
24 2.4610 N06455 Hastelloy C-4 65Ni-16Cr-16Mo-0.7Ti-3Fe-2Co-1Mn-0.08Si-0.01C
25 2.4602 N06022 Hastelloy C-22 56Ni-22Cr-13Mo-3Fe-2.5Co-0.5Mn-0.35V-0.08Si-0.01C
26 2.4675 N06200 Hastelloy C-2000 59Ni-23Cr-16Mo-1.6Cu-0.08Si-0.01C
27 2.4665 N06002 Hastelloy X 47Ni-22Cr-18Fe-9Mo-1.5Co-0.6W-0.1C-1mn-1Si-0.08B
28 2.4617 N10665 Hastelloy B-2 69Ni-28Mo-0.5Cr-1.8Fe-3W-1.0Co-1.0Mn-0.01C
29 2.4660 N10675 Hastelloy B-3 65Ni-28.5Mo-1.5Cr-1.5Fe-3W-3Co-3Mn-0.01C
30 N06030 Hastelloy G-30 43Ni-30Cr-15Fe-5.5Mo-2.5W-5Co-2Cu-1.5Mn-0.03C
31 N06035 Hastelloy G-35 58Ni-33Cr-8Mo-2Fe-0.6Si-0.3Cu-0.03C
32 1.4562 N08031 Nicrofer hMo31 31Ni-27Cr-6.5Mo-1.2Cu-2mn-0.01C
33 2.4605 N06059 Nicrofer hMo59 59Ni-23Cr-16Mo-1.0Fe-0.01C

Item 600 601 617 625 690 718 X750 825
C ≤0.15 s0.1 0.05-0.15 ≤0.08 $0.05 ≤0.08 s0.08 ≤0.05
Mn S1 ≤1.5 ≤0.5 $0.35 ≤0.5 50.35 S1 ≤1
Fe 6-10 rest s3 rest 7-11 rest 5-9 ≥22
P ≤0.015 ≤0.02 $0.015 -- -- -- -- --
S ≤0.015 ≤0.015 ≤0.015 ≤0.015 ≤0.015 ≤0.01 ≤0.01 ≤0.03
Si ≤0.5 ≤0.5 ≤0.5 ≤0.35 ≤0.5 ≤0.35 ≤0.5 ≤0.5
Cu ≤0.5 S1 -- ≤0.3 ≤0.5 ≤0.3 ≤0.5 1.5-3
NI 27.2 58-63 244.5 50-55 258 50-55 ≥70 38-46
Co -- -- 10-15 ≤10 -- S1 S1 --
AI -- 1-1.7 0.8-1.5 ≤0.8 -- 0.2-0.8 0.4-1 ≤0.2
T1 - - ≤0.6 ≤1.15 -- - 2.25-2.75 0.6-1.2
Cr 14-17 21-25 20-24 17-21 27-31 17-21 14-17 19.5-23.5
Nb+Ta -- -- 4.75-5.5 4.75-5.5 0.7-1.2 --
Mo - -- 8-10 2.8-3.3 -- 2.8-3.3 -- 2.5-3.5
B -- -- 50.006 - -- -- -- --


Product Show

product show

Monel alloy has excellent corrosion resistance to reducing media, and has good stability in hydrofluoric acid, alkali, seawater, H2S, H2SO4, H3PO4, organic acid and many other corrosive media, especially in hydrofluoric acid and alkali solutions, less stable than platinum and silver. The alloy has a certain SCC sensitivity and the working temperature is less than 200℃.Monel 400 copper-nickel alloy has high strength over wide temperature ranges (up to 1000F). Monel 400 springs can be used in corrosive applications up to 450F. The alloy performs well in high concentrations of salt water. Corrosion rates in surging seawater do not exceed 1 mpy. The most common specification for Monel 400 is ASTM B 164.

① Nickel-based high-temperature alloy plate

The main alloying elements are chromium, tungsten, molybdenum, cobalt, aluminum, titanium, boron, zirconium, etc. It has high strength and resistance to oxidation and gas corrosion at high temperatures of 650 to 1000°C. It is the most widely used alloy with the highest high temperature strength among high temperature alloys, manufacture aero-engine blades and high-temperature components

② Nickel-based corrosion-resistant alloy plate

The main alloying elements are copper, chromium and molybdenum. It has good comprehensive performance and can resist various acid corrosion and stress corrosion. The earliest application was nickel-copper alloy, also known as Monel alloy; in addition, there are nickel-chromium alloy, nickel-molybdenum alloy, nickel-chromium-molybdenum alloy, etc. Used to manufacture various corrosion-resistant parts.

③ Nickel-based wear-resistant alloy plate

The main alloying elements are chromium, molybdenum, and tungsten, and also contain small amounts of niobium, tantalum, and indium. In addition to its wear resistance, also has good anti-oxidation, corrosion resistance and welding properties. It can be used to manufacture wear-resistant parts, as a coating material to cover the surface of other base materials through surfacing and spraying processes.


Surface treatment

detaile


Feature

①Different grades

Stainless steel has different grades, correspond to different hardness, thermoplastic, plasticity and weldability. If you don't understand, you can tell us your requirements.

②Different surfaces

Stainless steel can be customized for different surfaces, and different surfaces have different applications. For example, 8k mirrors are generally used for decoration.

③High Quality

We have more than 30 years of experience in this industry and believe that we can satisfy any demand for stainless steel raw materials.

We have a strict detection system to support three-way detection


Application

application

Nickel alloys can be used in the following industries:

widely used in chemical equipment,off-shore oil driling companies,power generation,gas processing,specialty chemicals,sea water equipment,pharmaceuticals,petrochemicals and more.

High temperature components such as turbine blades, guide vanes, turbine disks, high pressure compressor disks,machine manufacturing and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines


Packing & Delivery

package

1. Package:export sea worthy package + water proof paper + wooden pallet or as customers' requirements.

2. The inner size of container is below:

20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high)

40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high)

40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high)

3.Delivery Details :7-15 dyas,or according to the order quantity or upon negotiation.
